SDP 2000

Typical Application

• Small-Scale Irrigation - Self-priming design for drawing water, ideal for gardens and agricultural plots, ensuring reliable smallscale irrigation.
• Water Boosting - Centrifugal impeller boosts water, providing consistent pressure for improved residential and commercial water outlets.
• Water Transfer - Portable pump for efficient water transfer between locations, suitable for filling tanks and supplying remote areas.
• Portable Applications - Handle for easy mobility, making it perfect for portable use in temporary irrigation setups or emergency water transfers.
• AutoPress System - Automatic booster system with diaphragm tank, pressure switch, and gauge for maintaining consistent water pressure in various applications.
• Temperature-Sensitive Applications - Suited for pumping thin, slightly aggressive liquids, with a maximum temperature handling of +35°C for diverse liquid transfer. Operates in ambient temperatures up to +40°C, providing versatility for use

Operating Conditions

• Max. Liquid Temperature: +60°C
• AmbientTemperature upto : +40°C
• Total suction lift up to: 8m

Component

• Pump body: Nylon
• Pump Support: Aluminium
• Motor Housing: Aluminium
• Impeller: PPO
• Motor shaft: AIS1304
• Mechanical Seal: SIC/Graphite

Motor

• Two-pole induction motor(n=2850 r.p.m)
• Insulation Class B
• Protection IP44
• Continous service S1
• Thermal protector for single phase
• Single-phase 220V/50Hz
