Typical Applications

Wells and boreholes for water extraction.
Remote irrigation systems using solar energy.
Livestock watering in rural areas.
Community water supply in off-grid locations.
Drip irrigation systems in agriculture.
Solar-powered water distribution in farms.
Off-grid water supply for homes.
Water transfer in rural areas.
Small-scale aquaculture projects.
Greenhouse irrigation using solar power.

Operating Conditions

Helical rotor pump for high lift. Higher efficiency, lighter
weight
High reliability, high-performance semiconductor devices
applied, 98% conversion efficiency. Patented dynamic VI
maximum power tracking (MPPT) , good stability, 99%
MPPT efficiency.
Centrifugal pump for big flow. Automatic operation. Full
protections. Ambient temperature -20 ~ +60℃.
Optional remote monitoring (built-in or external)

Technical Data

Mode	Type	Power				Rated Voltage	PV Configuration	Dimensions (mm)				Weight (kg)
Mode	Type	kW	Rated Motor Voltage (V)	Max Input Voltage (V)	Recommended MPP Voltage (V)	Rated Voltage	PV Configuration	A	B	C	Outlet	Weight (kg)
SATTE SFLO 200	Helical Rotor	0.2	24	60	30-50	6m³/day at 30m Head	1x330W/36Vx1String	365	170	195	¾"	6
SATTE SFLO 500	Helical Rotor	0.5	48	100	60-80	10m³/day at 40m Head	2x330W/36Vx1String	375	180	195	¾"	7
SATTE SFLO 600	Centrifugal	0.6	48	100	120-160	12m³/day at 30m Head	2x330W/36Vx1String	500	180	320	½"	7
SATTE SFLO 1100	Centrifugal	1.1	110	200	120-160	20m³/day at 40m Head	4x330W/36Vx1String	630	200	430		8
SATTE SFLO 1500	Centrifugal	1.5	110	200	120-160	20m³/day at 60m Head	6x330W/36Vx2Strings	690	200	490		10
SATTE SFLO 1500B	Centrifugal	1.5	110	200	120-160	50m³/day at 25m Head	3x335Wx2string	550	230	320	2"	10

Downloads SFLO Datasheet
